Megger BT51

“The BT51 Low Resistance Ohmmeter makes measurements by passing a current through the conductor under test and also monitoring the voltage across it. The test current is limited by a simple current limiting circuit and is measured by monitoring the voltage across a resistor. The test current is maintained at a nominal 2 A, and as the measurement is ratiometric, the reading is unaffected by any current variations.”

Specifications:

• Condition: Used
• Type: DLRO Milliohm meter
• Make: Megger
• Model: BT51
• Serial: S519999/1
• NSN: 6410-091/021102/1918
• Last Cal: Mar23
• Ranges: 2000mΩ and 20mΩ
• Resolution: 0.01mΩ
• Handspike: 2 x DH1, 2.5m Duplex Cable, 20A/30V AC/DC max
• Battery: Internal
• Accessories: User Manual, Hand Spikes
• Weight: 5.8Kg

Replacement price on this unit is approximately AUD$4500

This unit is item with a 30 Day Warranty.
